Price List of TATA 3D Weldmesh

TATA 3D Weldmesh

For the first time ever, Tata Wiron 3D Weldmesh offers you the features you have needed all this long.

This unique safety fence comes with a complete, hassle-free solution kit! Be it panels, posts, post-caps, high security spider clamps or mushroom bolts, it contains anything and everything you require. Gone are the days of buying screws or wires separately. Here comes Tata Wiron 3D Weldmesh as a complete solution to your safety needs!

The 3D Welded Mesh is designed for durability, coated with high-purity zinc and a special powder coating, ensuring protection for over 20+ years.

Tata Wiron 3D Weldmesh prices vary depending on height. Here is the latest prices for Tata Wiron 3D Weldmesh made of TATA Wiron wires. Buy Tata Wiron 3D Weldmesh made of Tata Wiron GI Wire online in Tamil Nadu on Deltaware.in

Specification #

Dimension of TATA Wiron 3D Weldmesh

Technical Specification of Tata Wiron 3D Weldmesh.

Minimum Order Quantity15 Panels or 120ft length
Panel HeightInstock: 4ft, 5ft & 6ft,
Against order: 7ft & 8ft
Panel Length2500mm (~= 8.2 ft) , Tolerance: +/- 3%
Mesh Size50x200mm
Wire MaterialG.I Wire
Wire Diameter4 mm
Wire Zn coating40 g/m2 minimum
Powder CoatingPure Polyester (PP)
Powder Coating Thickness80 microns minimum
Corrosion ResistanceCoating remain intact after 1000 hours.
(Salt Spray Test after powder coating as per ASTM B117)
Weld Strength21 kg/mm2(min) (as per IS 4948 (2002))
UV ResistanceNo deterioration in colour after 1000 hr. (at 63°C conducted as per ASTM D 1499)
Accessories IncludedEverything included, ready to install kit. refer Parts Included
ColorGreen (Instock),
Against order: 40+ colors

Weight Chart #

SizePanel (Kg)Post (Kg)Accessories (Kg)Total (Kg)
4ft9111.721.7
5ft11.212.6225.8
6ft13.614.46230.06
7ft16.616.22234.82
8ft17.818237.8

Note: Approx. weights are for reference, actual weight may change.

Parts and Accessories Included #

TATA Wiron 3D Weldmesh Fence Parts and accessories

TATA Wiron 3D Weldmesh comes with all accessories needed to fully install the fence. Here is the list of parts that come with each panel you purchase

13D Weldmesh Panel
2Rectangular Post
1. Base Plate Post with anchor bolts
2. Straight Post with anchor rods
2Mushroom Bolt
4Spider Clamp
5Closure Dummy
66A Anchor Rod or 6B Anchor Bolt (refer below images)

TATA Wiron 3D Weldmesh comes with all accessories needed.

Panel SizePost Height (m)Spide Clamp (nos)Bolt + Nut (nos)Anchor Rods
(or) Anchor Bolt (nos)
4ft1.8332 / 4
5ft2.1442 / 4
6ft2.4442 / 4

Note:

  • In the above table, the size is for straight posts. For base plate posts, the height of the post is the same as the panel height.
  • Based on post type either anchor rod or anchor bolt is supplied.
  • Below the ground length for straight post is 1.5ft (approx.) for concrete installation.

Installation Methods #

TATA Wiron 3D Weldmesh Fence buy online on Deltware.in

TATA Wiron 3D Welded Mesh offers two types of posts

  • Base Plate Post: This method involves securing the base plate post to an existing concrete structure or brickwork using an anchor bolt.
  • Straight Post with Anchor Rod: Straight posts with anchor rods are fixed in the ground using concrete mixture

TATA Wiron 3D Weldmesh installation method with base plate or anchor rod.

Base Plate Post #

Base Plate Post: This method involves securing the base plate post to an existing concrete structure or brickwork using an anchor bolt.

Buy Base Plate post type TATA Wiron 3D Weldmesh Fence online on Deltware.in

Straight Post #

Straight Post with Anchor Rod: Straight posts with anchor rods are fixed in the ground using concrete mixture

Buy Straight Post type TATA Wiron 3D Weldmesh Fence online on Deltware.in

Benefits of TATA Wiron 3D Weldmesh #

TATA Wiron 3D Weldmesh Fence buy online on Deltware.in

TATA Wiron 3D Weldmesh utilizes robust IP Powder coating and welding to ensure a strong and durable fencing solution, ideal for secure livestock containment and property protection.

Benefits of TATA Wiron 3D Weldmesh over Traditional Brick Wall

High Strength
Does not get deformed easily
Tested for max impact
Hassle-Free Installation Kit
Includes Panels, Posts,
Post-caps & Essential accessories
Longer Life
IP powder coating helps in
No corrosion, 1000 hours of tested
Beautiful Appearance
Gives an impressive look
No Fading, 1000 hours of tested
Stable Structure
Spot welding ensures firm joints
Anti Climb, Long Lasting
Cost Effective
25% cheaper than a brick wall
Less labour with faster installation

TATA Wiron 3D WeldmeshTraditional Brick Wall
25% CheaperVery High Cost
Superior AestheticsStandard Look
Zero Maintenance costPeriodical maintenance required
See through effect & visibilityOpaque wall
Easy to installInstallation is labour Intensive
Can be disassembled & reusedCannot be reused
